Plastic tube decoration
Digital Plastic tube decoration
DigiTube G2
The ultra-flexible ink-jet printing and lacquering machine for plastic tubes, sleeves and cartridges
The ultra-flexible ink-jet printing and lacquering machine for plastic tubes, sleeves and cartridges
DigiTube G3
The digital printing machine for tubes, sleeves and cartridges
The digital printing machine for tubes, sleeves and cartridges

Variable Data
- Printing variable data « each tube/sleeve can be different »
- Individualization and personalization for marketing opportunities
Print Quality
- Extremely high print quality comparable to Label decorating
- Flexibility in selection of the print design
- White available for clear and colored tubes
Efficiency
- Changeover times reduced to near zero
- Printing of single tube production and long production runs on same machine
- Cost-effective for small batches
- Increase of production output
- Significant reduction of startup and running waste
Ease to use
- Reduction of process steps
- Consistent print quality from beginning to end
- Quality not dependent on operator skills
Varnishing
- Standard varnishing unit with squeezing rollers
- Use of well proved varnish with glossy and matt effect or for hot stamping
- Spot lacquering

Efficiency
- Changeover time reduced to near zero
- Printing of single tube production and long production runs on the same machine
- Increased production output
- Significant reduction of startup and production waste
- No ink mixing required
New Workflow
- No printing plates
- Almost no back loop for corrections
- A fast and efficient way for decoration
- Reduced production processes enable new business models with on-time delivery
Print Quality
- High print quality comparable to IML / Sleeve / Label decorating
- Flexibility in selection of the print design
- Print without overlap > 360°
- White available for clear and colored containers
- Glossy effect
Variable data
- Printing variable data “each tube can be different”
- Individualization and personalization for marketing opportunities
- High volume of variable codes easy to manage
Technical Data
DigiTube G2 | DigiTube G3 | |
|---|---|---|
Min./max. tube diameter
| 19 – 50 mm | 19-50 mm |
Min./max. tube height | 60 – 215 mm | 60 – 215 mm |
Max. production speed | 120 tubes/min | 150 tubes/min |
Colours | W + CMYK | W + CMYK + OVG + Varnish |
Tube head incl. cap height max. | 50 mm | 50 mm |
Visual resolution, up to | 1200 dpi | 1200 dpi |
Mandrels | 24 | 24 |
Print height, up to | 210 mm | 205 (215) mm |
Weight of main machine
| ~13,000 kg
| ~13,000 kg
|
